Mechanical Four Rope Grabs

13048 1pc.  Mechanical Four Rope Clamshell Grab

  • Type : MFC7000
  • Execution: Four  Rope operated
  • For handling rolling bulk materials up to max 1.6 ton/m3
  • Capacity : 7m³
  • Empty Weight : appr. 5.400 kg

Main Dimensions:

  • Spread closed : approx. 2600mm
  • Height closed : approx. 3600mm
  • Width : approx. 2500mm




12945 1pc.  Mechanical Four Rope Clamshell Grab



  • Type : MFC8000
  • Execution: Four  Rope operated
  • For handling rolling bulk materials, or for light dredging purposes
  • Capacity : 8m³
  • Empty Weight : appr. 7.300 kg



Main Dimensions:







  • Spread closed : approx. 3100mm
  • Height closed : approx. 3900mm
  • Width : approx. 2840mm












x 1pc.  Mechanical Four Rope Timber Grab

  • Type : MFTG-600-2500
  • Execution: Four  Rope operated
  • Capacity : 2.5m2
  • Empty Weight : appr. 1.900kg

Main Dimensions:

  • Spread closed : approx. 1600mm
  • Height closed : approx. 3600mm
  • Width : approx. 1100mm
